Matek Servo PDB With BEC 5.5-36V to 5-7.2V

  • $8.50
    Unit price per


Matek's Servo PDB provides clean voltage regulation for servos and other accessories that need 5-8.2V.  With 6 PWM outputs, this little PDB can be connected to flight controllers that do not have actual PWM outputs or BEC for servos.  This is a must-have for any plane with servos as it is critical they are powered with clean and dedicated power.


  • 5.5V to 36V Operating Input Range
  • Vx for servos,  5V, 6V, 7.2V, 8.2V Adj. Default is 5V.
  • 4A Continuous load current, 7A Burst
  • Maximum Duty Cycle: 100%,   when input voltage< setting value,  Regulator output voltage = Input voltage
  • Output Short-circuit tolerant (3 seconds)
  • No protection for reversed input polarity
  • Pins distance: 2.54mm
  • Size & Weight: 26 x 21 x 5mm, 4g
  • Packing: 1x SVPDB-8S,  Dupont 2.54mm pins


  • Flight controllers without dedicated BEC for servos
  • Reduces circuit loss and voltage drop on servo power wires for big scale RC Airplane

Wiring Diragram:

Matek Servo PDB
Matek Servo PDBIncludes:
1x Matek Servo PDB With BEC 5.5-36V to 5-8.2V
Dupont 2.54mm Pins
