Diatone's Mamba MK4 (fourth generation) F722 Mini flight controller is a redesign of its already fantastic line of flight controllers. Improvements include making the products easier to use by increasing soldering pad sizes by 30%, pad spacing by 100%, adding USB-C, additional UARTS and I2C, better filtered BEC, and more.
What's New?
A completely different pad style has been redesigned to increase pad area by 30% and pad spacing by 100%, reducing solder errors and associated failures.
- The pad area increased by 30%
- Pad spacing increased by 100%
- MP9943 synchronous rectifier BEC
- Mini series upgrade DJI interface and 5V 15W/9V 18W 2 set BEC
- USB Type C
- 6 Set UART and I2C
- Full range of integrated Flash and Barometer
- 4 Set Power Protection
- Mini series FC use 2mm and 3mm mounting holes, special dampening ring
- Upgrade the twisted pair anti-jamming cable and reinforcement process
Specifications:
- MCU: STM32F722
- Frequency: 216MHz
- Gyro: Gyro ICM42688P
- Barometer: SPL06
- OSD: AT 7456E
- Blackbox: 16M Memory
- UARTS: 6 Sets
- I2C: Yes
- F.Port: Yes
- Buzzer: Yes
- Current: Yes
- ESC Signal: 8 Sets
- BEC 3.3V: 0.5A
- BEC 5V: 2.5A
- BEC 9V: 2A
- MB LED: Yes
- BF LED: Yes
- Air Unit Port: Yes
- VTX Switch: Yes
- BEC Protection: Yes
- Receiver Protection: Yes
- TVS Protection: Yes
- Input: 6S LiPo
- Firmware: Betaflight
- Mounting: 20.0x20.0mm, M3/M2
- Size: 29.0x29.5x6.5mm
- Weight: 6.0g
