iFlight Nazgul Evoque F7 O4 6S HD BNF
Introducing the new 7-inch Nazgul Evoque—packed with 6 key upgrades for immersive long-range flights. It inherits the series’ DC geometry, delivering cinematic shots free of prop obstruction. Equipped with the DJI O4 Pro Air Unit, it supports seamless video capture and output, letting you capture unobstructed mountain and sea views effortlessly. Dual tuning presets (Long-Range/Freestyle) adapt to your needs, paired with iconic Dynamic LED effects for standout recognition and tech flair. Enjoy extended flight time to fly and create without limits.
Dual Official Tuning Presets
Nazgul Evoque series upgrades with two official PID presets, unlocking new exploration possibilities for pilots. These presets can be selected directly in the PID Tuning tab of the Betaflight Configurator.
Dualband Dual-Antenna, Enhanced Long-Range Stability
With an optional ELRS dualband dual-antenna receiver, supporting simultaneous 2.4GHz + 900MHz communication. Paired with a dual-antenna, fan-shaped distributed layout for omnidirectional signal reception, it ensures stable, controlled long-range flights even in complex environments.
Upgraded Borg Stack
The upgraded Borg Stack features a built-in anti-spark filter, dual independent BEC power supply (12V 2A with VTX switch + 5V 25A) for stable power, and a built-in polymer capacitor to extend device lifespan.
Fin-Shaped Cooling Channel
The fin-shaped cooling channel design enhances heat dissipation and ensures stable long-range flight performance. It comes with Dynamic LED effects full of recognition and technological sense.
Flagship Recording Capability Equipped with DJI O4 Air Unit Pro
Upgraded with a 1/1.3-inch image sensor, delivers remarkable performance in low-light and night environments. Capture low-altitude, high-speed flight footage in 4K resolution with an ultra-wide 155° FOV. Experience the immersive visual impact of flight like never before, with crisp 4K output that effortlessly meets your creative needs.
Specifications:
- Product Name: Nazgul Evoque F7 O4 6S HD
- Geometry: Deadcat(DC)
- FC: Borg Mini F7 Flight Controller
- ESC: Borg 60R ESC
- Video Transmission: DJI O4 Air Unit Pro
- Receiver: ELRS 2.4GHz/868/900MHz Dualband Diversity
- Frame: 321mm wheelbase
- Motor: XING2 2809 1250KV motors
- Prop: HQ 7.5X3X3 propellers
- Weight: 765±5g(Without Battery)
- Takeoff Weight: Approx. 1620±5g (incl. 21700 6S 10000mAh)
- Dimensions (L×W×H): 284*283*53mm
- Max Speed: 140km/h
- Maximum Takeoff Altitude: 7000 m
- Max Hover Time: Approx. 25min with 6S 8000-10000mAh battery No Load
- Recommended load: 800g
- Operating Temperature Range: -20° to 40° C
- Antennas: Dual Antennas
- GNSS: GPS+SBAS+Galileo+QZSS+Glonass
Includes:
1x iFlight Nazgul Evoque F7 O4 6S HD BNF
1x Battery Pad
2x 7.5 Inch Prop (Pairs)
2x Battery Strap
