Immersion RC Vortex 230 Mojo

  • $329.00
    Unit price per
  • Save $50.00


From the same team that brought you the successful ARF/RTF Vortex quads comes something with a little more spunk. The Vortex 230 Mojo is a crossover race/freestyle quad, excellent on the track, and heaps of fun for freestyling. Un-box, install your receiver, mount the props and plug in your battery and be ripping around your local track or field in 5 minutes flat.

Perfect for beginners looking for an easy way to get started in this hobby.

Fantastic for seasoned veterans looking for an ultra-fast, high performing 230 sized quad.

Vortex 230 Mojo - the latest in Immersion RC's line of ready built quads that perform amazingly well.

This little guy features Twin ‘F3’ Processors and 4th Gen 32bit 30A EzESCs, With DSHOT support for the ultimate in flight performance. The chamfered Carbon Fibre, and a new blend of molded, tough plastic and lightweight titanium torx hardware means durability that allows you to fly without fear. Even all the electronics are conformally coated for protection from the elements.

The Vortex 230 Mojo has a center of gravity at the propeller level and a low moment of inertia thanks to the centralized mass. This gives maximum authority to the flight controller to provide crispy sharp stops or buttery smooth rolls. Featuring pro-tunes fine-tuned by none other than Chad Nowak/FinalGlideAus and Travis Samson/GAPiT you can fly like they do right out of the box (pilot skills not included, prior training required!).

The huge performance boost over the Vortex 250 Pro is thanks to modern BortherHobby Returner R3 2206 motors that are over 50% more powerful and the weight savings of close to 100 grams. The Vortex 230 Mojo will rival any modern day top mount freestyle quad.


  • Weight: ~348g without battery
  • Power Requirements: 4s LiPo
  • ESCs: Full Custom, 32bit, 30A cont. 40A peak, rotorSENSE, OneShot125/42, Multishot, DSHOT-600
  • Motors: BrotherHobby R3 2206-2300kV
  • Props: Black HQ 5x4.3x3 V1S Tri-Blades
  • Flight Camera: 600TVL CCD , FatShark 'Gen3' Sony Sensor/Sony Chipset
  • VTX:  Tramp HV ( <1mw to >600mw of power )
  • Receiver Compatibility: CPPM, S-Bus, Spektrum™, XBus, SumH, SumD, iBus (no external adapters required)
  • Flight Time: Highly dependent upon battery, and flying style

1x Vortex 230 Mini Race Quad, Fully assembled and flight-tested
2x ImmersionRC Branded battery straps (Installed)
1x SpiroNET Omni 5.8GHz antenna (Stubby, v2)
1x PPM Interface Cable
1x Spektrum Interface Cable
1x SBus Interface Cable
8x HQ 5x4.3x3 V1S 3-Blade Props
Foam piece for HD camera mounting
