TBS M7 GPS Glonass

$10.50   In Stock

TBS M7 GPS Glonass
The perfect small sized GPS for your needs.  Quick to lock on, fantastic performance and sensitivity.

Specifications:

  • Chipset - G7020-KT
  • Frequency - L1, 1575.42MHz
  • Baud Rate - 4800,9600,19200,38400,57600,115200bps
  • Channel - 56
  • Sensitivity - (Tracking: -162dBm) | (Capture: -160dBm) | (Cold Start - 148dBm)
  • Cold start - Average 29 seconds
  • Warm start - Average 28 seconds
  • Hot start - Average 1 second
  • Accuracy - (HorizontalPosition:Autonomous<2.5m average) | (SBAS < 2.0m average) | (Timepulse signal: RMS 30 ns)
  • Maximum height - 50000m
  • Maximum speed - 500 m/s
  • Maximum acceleration - ≦ 4G
  • Refresh Rate - 1-10 Hz
  • Size - 18 x 18 x 6mm
  • Weight - 4.3g
  • Input Voltage - 3.3V-5V

Includes:
1x TBS M7 GPS Glonass
